#FLUKE FIBER QUICKMAP PRO#
#FLUKE FIBER QUICKMAP FREE#

± (1 m + 0.1 % x length) for reflective incidents1 ± (3 m + 0.1 % x length) for non-reflective incidents2ġm after the bulkhead connector when the bulkhead reflectance is 3 m after an incident when the incident reflectance is 10 m after the bulkhead connector or any prior incident when the bulkhead reflectance is <-35 dB and the reflectance of any prior incident is <-35 dB. Operating relative humidity (without condensation)ĩ5% (10✬ to 35✬) 75% (35✬ to 40✬) uncontrolled 11 dBĭistance accuracy (0 m to 1500 m or 0 ft to 4921 ft) Rugged construction vibration and drop tested to 1 meter.Quickly discover reflective incidents, causes of bit error rates and the primary source of network performance degredation. Fiber Quickmap features a six-second test time in locating high loss incidents or breaks. Long battery life, 1,500 tests (typical) from 2 AA alkaline batteries The Fluke Networks FQM-Main Fiber Quickmap is designed for fiber troubleshooting to quickly locate incidents in multimode fiber.Optional LC, ST and FT interchangeable adapters are available.Backlighted display turns off automatically Change the Index of Refraction (IOR) to improve fiber length accuracy.Six-second test time-no more blind troubleshooting that can waste hours FQM-MAIN from Fluke Networks at Allied Electronics & Automation, part of RS Group.

Parts, accessories, product repairs and services are warranted for 90 days, unless otherwise stated.

#FLUKE FIBER QUICKMAP FREE#

Connect your fiber and press the Test button. Fluke Networks mainframe products will be free from defects in material and workmanship for one year from the date of purchase, unless stated otherwise herein.

Detects live optical signals before it begins testing.

Find potential sources of high bit error rates caused by reflectance from dirty or poor connections.

Locate severe bends, high-loss splices, breaks and dirty connectors in multimode fiber.

Measure up to 4,921 feet (1,500 metres) of fiber in seconds Like an OTDR, a laser sends light pulses through the fiber and measures the power and timing of light reflected from high loss connections and splices, and the end of the fiber.

#FLUKE FIBER QUICKMAP PRO#

Fiber QuickMap Kit Works on multimode fiber, 9/125µm and 62. Fiber OneShot PRO and Fiber QuickMap measure length and identify high loss events on single mode (Fiber OneShot PRO) and Multimode (Fiber QuickMap) fiber optic cable. Works on multimode fiber, 50/125µm and 62.5/125 µm Fluke Networks FQM-100-M Fiber QuickMap Multimode Fiber Distance and Fault Locator w/ UPC Cord and Case.
